This product is a high-fidelity pickup with two high-sensitivity directional condenser microphones, using ambient noise cancellation (ANC) environmental noise cancellation technology, built-in AGC processing technology, taking into account the processing of both large and small sounds, with a maximum pickup range of 150 square meters, including a dedicated potentiometer, stable and reliable volume adjustment; built-in lightning protection, power polarity reverse protection and electrostatic protection. It is suitable for banks, conference recording, teaching recording, security inspection, subways, museums and other places.
* Adopting two high-sensitivity directional condenser microphones, the sound is clear and natural;
* Adopts Ambient noise cancellation (ANC) technology;
* Built-in AGC processing technology, taking into account the processing of both loud and small sounds;
* Equipped with a dedicated potentiometer, the volume adjustment is stable and reliable;
* Built-in lightning protection, power polarity reverse protection and electrostatic protection;
* It complies with RoHS standards and does not contain any hazardous substances banned by the EU in its structure.
|
Pickup range |
5-150 sqm |
|
Audio transmission distance |
3000m |
|
Sensitivity |
-30dB |
|
Frequency response |
100Hz～16KHz |
|
Directivity |
Omnidirectional |
|
Signal-to-noise ratio |
80dB (1m 40dB sound source SPL) 50dB (10m 40dB sound source SPL) 1KHz at 1Pa |
|
Dynamic range |
104dB(1KHz at Max dB SPL) |
|
Maximum sound pressure |
120dB SPL (1KHz, THD 1%) |
|
Output impedance |
Maximum 600 ohms unbalanced |
|
Output signal amplitude |
2.5Vpp |
|
microphone |
Diaphragm condenser microphone |
|
Number of Microphones |
Dual Microphones |
|
Signal processing circuit |
ANC environmental noise cancellation technology, AGC processing technology |
|
Protection circuit |
8KV Air contact ESD, lightning protection, power polarity reverse protection |
|
Drive capability |
Can directly drive headphones |
|
Connection |
3 leads (power, audio, common ground) |
|
Transmission cable |
3 core 0.5mm² RVVP shielded cable |
|
Supply voltage |
DC 12V regulated power supply |
|
Supply current |
60mA |
|
Operating temperature |
0℃～50℃ |
|
Color |
White |
|
Shell material |
Metal |
|
Dimensions |
Φ80mm×25mm |
|
Weight |
0.17kg |
